Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: MOKO
  • Model Number: MK-BD-Series
  • Base Material: FR4/Aluminum
  • Copper Thickness: 1oz~4oz
  • Board Thickness: 1.0~1.6mm
  • Min. Hole Size: 0.1mm
  • Min. Line Width: 0.1mm
  • Min. Line Spacing: 0.1mm
  • Surface Finishing: HASL
  • Product name: 3w 5w 7w 9w 12w 15w 18w round led pcb
  • led chip brand:: pistar, sanan, as customer requirement
  • chip type: 730
  • chip voltage: 3.0-3.3v, 3.3-3.6v
  • CRI>: 80
  • CCT: 3000-3500K, 4000-4500K, 6000-6500K
  • Lifetime: >50000h
  • Testing service:: 100% pcb testing, 100%led pcb testing
  • Solder Mask:: Blue/Red/Green/White
  • Certification: CE, ROHS

Packaging & Delivery

Packaging Details: 15*15*10cm
Delivery Detail: Shipped in 5 days after payment
Our Services

High Lumens 5730SMD LED PCB, 5w 7w 9w 12w LED Module For Bulb light

1. We will reply for you within 24hours once we get your inquiry.
2.Design and produce almost any LED pcb as your requirement.
3.100%testing guarrantees stable quality, ISO 9001:2000 ,UL, RoHS certification.
4.Short delivery time



Quotation requirement



a) PCB size
b) led chip's brand, model, lumens, CRI, CCT
c) Sample photos
d) Gerber file and BOM list



Advantage

1.LEDs driven directly from AC line voltage, no AC/DC conversion.
2.Advanced IC technology, no electrolyte capacitor, longer lifetime.
3.Compact size and low-cost for design flexiblity.
4.Excellent power factor(>0.90) and low THD(<20%).Comply with EMC and other safety requirements.
5.High power conversion efficiency(>90% typical). High system luminous efficiency(>90lm/W)
6.Compatible with leading edge dimmers and most of Triac dimmers
7.Suitable for light bulb, candle light, downlight etc.



PowerPhotosSpecsPrice
3W 6pcs 5730 leds
Sanan led chip brand
Diameter: 32mm
Lumens:100-110lm/w, CRI>70
CCT: 3000~3500K; 4000~4500K; 6000~6500K
Thickness: 1mm
0.12USD
5W10pcs 5730 leds
Sanan led chip brand
Diameter:50mm
Lumens:100-110lm/w, CRI>70
CCT: 3000~3500K; 4000~4500K; 6000~6500K
Thickness: 1mm
0.20USD
7W14pcs 5730 leds
Sanan led chip brand
Diameter:50mm
Lumens:100-110lm/w, CRI>70
CCT: 3000~3500K; 4000~4500K; 6000~6500K
Thickness: 1mm
0.25USD
9W18pcs 5730 leds
Sanan led chip brand
Diameter:65mm
Lumens:100-110lm/w, CRI>70
CCT: 3000~3500K; 4000~4500K; 6000~6500K
Thickness: 1mm
0.36USD
12W24pcs 5730leds
Sanan led chip brand
Diameter: 65mm
Lumens:100-110lm/w, CRI>70
CCT: 3000~3500K; 4000~4500K; 6000~6500K
Thickness: 1mm
0.45USD
15W30pcs 5730 leds
Sanan led chip brand
Diameter:85mm
Lumens:100-110lm/w, CRI>70
CCT: 3000~3500K; 4000~4500K; 6000~6500K
Thickness: 1mm
0.73USD

Production line procedure:

Board CutCarbon PrintingCircuit ExposureCircuit QCEtchingEtching QCPrint Solder mask inkSurface Finish(F-HASL)Surface finish QCDrillV-cutE-testPunchFQCPacking



Lead time:



Lead time for sample2~3days for single-side board
4~5days for double-side board
24~48hours for ugent
Lead time for opening mould3~5days for normal mould
5~7days for hard mould
Lead time for mass production5~7days for single/double board

Certification:
Payment:

Company Information

Moko Technology Ltd found in 2001 is a one of leading pcb manufacturer in China, focus on providing LED light pcb,Our product covers a wide range, including all Aluminum led pcb, finish bulb light, tube light, flood light, ceiling light etc.



And customized Aluminum led pcb is our main service. On time deliveries service and competitive price for our customer is our target, welcome to our company.







FAQ



Q1: Can I have led samples to test?
A: Yes,we are pleased to supply module samples to test and check quality,mixed sample order is available. Please note buyer should pay for shipping cost.

Q2: What’s the lead time?
A: Sample: 1-7 working days.
Mass production: 8-15 working days.

Q3:Can you design pcb and make files for us?
A:yes,We have a professional drawing engineers' team than you can trust.

Q4:How to proceed an order for led module?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.


Q5: If I order big quantity, what's the good price?
A: Please send the details enquiry to us, such as the Item Number, Quantity for each item, Quality request, Logo, Payment Terms, Transport method, Discharge place etc. We will make the accurate quotation to you as soon as possible.



Q6:Does all led pcb tested
A:Yes, we ensure that each piece of led pcb will be tested before shipment, we ensure the goods we sent with good quality.
